Introduction: The Role of Valves in Water Treatment Plants
Valves are essential components in every water and wastewater treatment plant, responsible for regulating, isolating, and controlling the flow of raw water, treated water, and sludge. They help operators maintain precise process control across multiple stages — from filtration and disinfection to distribution and waste discharge.
In a facility where efficiency, hygiene, and reliability are critical, selecting the right valve type and material ensures long-term performance and compliance with environmental standards.
As a leading Singapore-based marine and industrial valve stockist and distributor, Aik Soon Hardware supplies robust valve solutions trusted by water utilities, engineering contractors, and industrial users across Southeast Asia.
This article explores the most common valve types found in water treatment plants, their applications, materials, and how to choose the right one for your system.
1. Gate Valves
Description:
Gate valves are linear motion valves that use a wedge-shaped gate to start or stop flow. They are designed for on/off isolation rather than flow regulation.
Use Case:
Material Selection:
Where Found:
Gate valves are commonly used in intake stations, filtration units, and distribution manifolds, providing a tight seal when isolating parts of the system for maintenance.
Selection Tip:
Opt for rising stem gate valves for visible open/close indication in large plants, and resilient-seated gate valves for potable water lines to prevent leakage.
2. Butterfly Valves
Description:
Butterfly valves use a rotating disc to control flow, requiring only a quarter turn to open or close. They are lightweight, compact, and suitable for large-diameter pipelines.
Use Case:
-
Raw water and treated water pipelines
-
Aeration and filtration systems
-
Chemical dosing and sludge handling lines
Material Selection:
Where Found:
Often installed in main process headers, pump stations, and filtration systems, where quick actuation and tight shut-off are needed.
Selection Tip:
Choose double- or triple-offset butterfly valves for applications requiring higher pressure or minimal seat wear.
3. Ball Valves
Description:
Ball valves use a spherical disc to control flow, offering fast shut-off, tight sealing, and low torque operation.
Use Case:
Material Selection:
-
PVC or CPVC for non-corrosive chemical dosing
-
Stainless steel (316) for corrosive or pressurized service
-
PTFE seats for excellent chemical resistance
Where Found:
Ball valves are prevalent in chemical dosing skids, chlorination systems, and instrumentation loops, where precision and chemical compatibility are essential.
Selection Tip:
Use full-bore ball valves for unrestricted flow in pipelines and multiport ball valves for switching between flow paths in dosing applications.
4. Check Valves
Description:
Check valves, or non-return valves, allow flow in only one direction to prevent backflow that could contaminate clean water or damage pumps.
Use Case:
Material Selection:
Where Found:
Commonly installed on pump outlets, filter discharge lines, and chemical dosing points to protect equipment and maintain process hygiene.
Selection Tip:
Choose spring-loaded or swing check valves depending on flow velocity — swing types for low-velocity flow, spring-loaded for vertical installations.
5. Diaphragm Valves
Description:
Diaphragm valves use a flexible rubber diaphragm that presses against a weir to control flow. They are particularly effective for slurries, viscous fluids, and chemical dosing.
Use Case:
Material Selection:
-
EPDM, PTFE, or Viton diaphragms for chemical resistance
-
PVC or cast iron bodies depending on fluid type
Where Found:
Typically installed in chemical dosing stations, sludge treatment lines, and clarifiers, where smooth, leak-free operation is critical.
Selection Tip:
Diaphragm valves are ideal for corrosive or dirty fluids. Ensure the diaphragm material matches the fluid composition and temperature.
6. Air Release & Vacuum Valves
Description:
These valves automatically release trapped air or admit air into pipelines to prevent vacuum conditions that can damage equipment or disrupt flow.
Use Case:
Material Selection:
Where Found:
Usually installed at high elevation points and pump discharge headers to ensure smooth pipeline operation and prevent air locking.
Selection Tip:
Use combination air valves for systems requiring both air release and vacuum protection during filling and draining cycles.
Selecting the Right Valve for Water Treatment Applications
When selecting valves for water treatment facilities, engineers should consider:
-
Media Type – Raw water, treated water, sludge, or chemicals
-
Operating Pressure & Temperature – Match with the appropriate valve class
-
Corrosion Resistance – Use coated iron or stainless steel in humid, corrosive environments
-
Ease of Maintenance – Choose designs with accessible seats and seals
-
Compliance Standards – Ensure valves meet AWWA, ISO, or BS standards
At Aik Soon Hardware, our technical specialists guide clients through selecting valves that ensure safety, efficiency, and durability in water and wastewater treatment systems.
Conclusion: Reliable Valves for Reliable Water Management
Water treatment plants depend on precise flow control to deliver safe, clean water to communities and industries. Each valve — from isolation to control — plays an essential role in ensuring that processes run smoothly, safely, and sustainably.
As a trusted Singapore-based marine and industrial valve supplier, Aik Soon Hardware delivers a comprehensive range of water treatment valves that meet the highest quality and certification standards. With our extensive inventory and technical expertise, we help clients build efficient and reliable water systems that last.
